DIFFUSERS
JD-1001
- Four way square diffusers of 150 x 150 mm neck size and 275 mm x 275 mm outer size.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusres will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel finish.
JD-1002
- Four way square diffusers of 225 x 225 mm neck size and 350 x 350 mm outer size.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusres will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel finish.
JD-1003
- Four way square diffusers of 300 x 300 mm neck size and 425 x 425 mm outer size.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusres will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel finish.
JD-1004
- Four way square diffusers of 375 x 375 mm neck size and 500 x 500 mm outer size.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusres will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel finish.
JD-1005
- Four way square diffusers of 450 x 450 mm neck size and 575 x 575 mm outer size.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel finish.
JD-1006
- Four way square diffusers of 375 x 375 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1007
- Four way square diffusers of tegular Type 375 x 375 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1008
- Four way square diffusers of 450 x 450 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1009
- Four way square diffusers of tegular Type 450 x 450 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1010
- Plaque diffusers of 450 x 450 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1011
- Plaque diffusers of 375 x 375 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1012
- Plaque diffusers of 300 x 300 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1013
- Two way square diffusers of 450 x 4500 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm. This diffusers is available with neck size from 150 mm , 225 mm , 300 mm , 375 mm and 450 mm
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1014
- Four way square diffusers of 375 x 375 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm. These type diffusers having a adaptor for connecting to the duct collar of different dimensions.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1015
- Four way square diffusers of 375 x 375 mm neck size and 595 x 595 mm outer size to suit ceiling grid size of 600 x 600 mm. These type diffusers having a adaptor for connecting to the duct collar of different dimensions. The figure shows a an extruded aluminium opposed blade collar damper connected to the adaptor.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Both supply and return air diffusers are available and supply air diffusers will have collar damper made of extruded aluminium with powder coating of black colour or GI collar damper of black enamel paint finish.
JD-1016
- Perforated diffusers plates are made with precisely punched capsule holes are used extensively for distributing the air uniformly like a laminar flow pattern over a large surface area.
- Material of construction – Aluminium sheets of 1.20 mm thickness.
JD-1017
- Perforated diffusers plates are made with precisely punched round holes are used extensively for distributing the air uniformly like a laminar flow pattern over a large surface area.
- Material of construction – Aluminium sheets of 1.20 mm thickness.
- Finish – Powder Coated in different colours to suite customer requirements.
JD-1018
- Perforated diffuser plates are made to suit 600 x 600 mm ceiling grid size to have 595 x 595 mm outer size including the extruded aluminium tegular type frames
- Material of construction – Extruded aluminium frames and 1,2 mm aluminium sheets.
- Finish – Powder Coated in different colours to suite customer requirements.
JD-1019
- Two slot diffusers of 80 mm neck size and about 100 mm outer size.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Designed most aesthetically. Available in 1 to 8 slots with 20 mm slot dimension having maximum length of 3.66 meter for a single piece
JD-1020
- Four slot diffusers of 150 mm neck size and about 180 mm outer size.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Designed most aesthetically. Available in 1 to 8 slots with 20 mm slot dimension having maximum length of 3.66 meter for a single piece.
JD-1021
- Three slot diffusers of 110 mm neck size and about 130 mm outer size.
- These diffuser having hit and miss damper to precisely control the volume of air passing through the diffusers. Generally the dampers are fitted in the slot diffusers where duct collars are provided for air distribution.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Designed most aesthetically. Available in 1 to 8 slots with 20 mm slot dimension having maximum length of 3.66 meter for a single piece.
JD-1022
- Two and three slot linear diffusers.
- These diffuser having hit and miss damper to precisely control the volume of air passing through the diffusers. Generally the dampers are fitted in the slot diffusers where duct collars are provided for air distribution.
- Material of construction – Extruded Aluminium.
- Finish – Powder Coated in different colours to suite customer requirements.
- Designed most aesthetically. Available in 1 to 8 slots with 20 mm slot dimension having maximum length of 3.66 meter for a single piece.
JD-1023
- Round diffusers of 150 mm dia neck size and 250 mm outer size
- Material of construction – Aluminium sheets of suitable thickness using spinning technology.
JD-1024
- Round diffusers of 200 mm dia neck size and 300 mm outer size
- Material of construction – Aluminium sheets of suitable thickness using spinning technology.
- Finish – Powder Coated in different colours to suite customer requirements.
JD-1025
- Round diffusers of 250 mm dia neck size and 350 mm outer size
- Material of construction – Aluminium sheets of suitable thickness using spinning technology.
- Finish – Powder Coated in different colours to suite customer requirements.
JD-1026
- Round diffusers of 300 mm dia neck size and 400 mm outer size
- Material of construction – Aluminium sheets of suitable thickness using spinning technology.
- Finish – Powder Coated in different colours to suite customer requirements.
JD-1027
- Round diffusers of 300 mm dia neck size and 400 mm outer size, fitted with volume control damper
- Material of construction – Aluminium sheets of suitable thickness using spinning technology.
- Finish – Powder Coated in different colours to suite customer requirements.
JD-1028
- Round diffusers of 300 mm dia neck size and 400 mm outer size, fitted with volume control damper. The volume control damper will be butterfly type and the quantity of air can be adjusted by the operating knob.
- Material of construction – Round Diffusers – Aluminium sheets of suitable thickness using spinning technology. Volume Control Damper – GI sheets of suitable thickness.
- Finish – Powder Coated in different colours to suite customer requirements.
JD-1029
- A view of the supply air diffusres of neck size 375 x 375 mm and having an outer size of 595 x595 mm fitted with extruded aluminium powder coated collar damper. The centre core of the diffuser ican be removed without any tools and it is spring loaded.
JD-1030
- Jet diffusers are available of 150 mm dia neck size to 350 mm neck size.
- Material of construction – Aluminium sheets of 1.20 mm thickness using spinning technology.
- Finish – Powder Coated in different colours to suite customer requirements.
JD-1031
- Swirl diffusers are available for ceiling grid sizes of 595 x 595 mm and it comes with differene slots.
- Material of construction – Aluminium sheets of 1.20 mm
- Finish – Powder Coated in different colours to suite customer requirements.
JD-1032
- Spot diffusers are specially designed to achieve a long throw in air conditioning systems and are commonly used in large indoor spaces like airports, shopping malls etc.
- Finish – Powder Coated in different colours to suite customer requirements.
